How Does a Diaphragm Pressure Gauge Work? A diaphragm pressure gauge uses a flexible diaphragm that deflects when pressure is applied. This movement is mechanically transferred to the indicating mechanism, causing the pointer to move across the calibrated dial and display the measured pressure. The diaphragm also helps isolate the internal measuring mechanism from the process medium, making these gauges suitable for demanding applications.
